SONICC05
DESIGNED TO DOMINATE. BUILT TO WIN.
SONIC | ELITE PREMIUM GAMING

C05PERFORMANCE GAMING

DESIGNED TO DOMINATE.
BUILT TO WIN.

A premium gaming chassis engineered for powerful hardware, immersive cooling, and a clean modern build.

VIEW SPECIFICATIONS
CONTACT FOR AVAILABILITY
SONIC C05 gaming case
C05  ·  PERFORMANCE GAMING  ·  PERFORMANCE,  ·  C05  ·  PERFORMANCE GAMING  ·  PERFORMANCE,  ·  C05  ·  PERFORMANCE GAMING  ·  PERFORMANCE,  ·  C05  ·  PERFORMANCE GAMING  ·  PERFORMANCE,  ·  C05  ·  PERFORMANCE GAMING  ·  PERFORMANCE,  ·  C05  ·  PERFORMANCE GAMING  ·  PERFORMANCE,  ·
340MM MAX GPU LENGTH
360MM RADIATOR SUPPORT
165MM MAX CPU COOLER
7PCI EXPANSION SLOTS
The C05

A PREMIUM GAMING CHASSIS ENGINEERED FOR POWERFUL HARDWARE, IMMERSIVE COOLING, AND A CLEAN MODERN BUILD.

Technical

PRECISION IN EVERY DIMENSION

Designed to deliver impressive hardware compatibility while maintaining a refined gaming footprint.

Chalk sketch of the C05 front view
390 mm · WIDTH470 mm · HEIGHT
DEPTH215mm · DEPTH
C05

MESH THAT
BREATHES.

SONIC C05
MESH SIDE PANELTEMPERED-GLASS FRONT, MESH SIDE PANELTRI-SIDE VENTILATION
INSIDE THE C05

EXPLODED VIEW

  1. 01TEMPERED GLASSThe glass panel lifts away to reveal the build.
  2. 02FAN WALLThe side-mounted fans slide out as a unit.
  3. 03POWER BAYThe power supply sits in its own shroud at the base.
  4. 04CHASSISMotherboard, GPU and radiator space stay in the frame.
Scroll to pull the C05 apart. Illustrative layers made from the product photo.
C05 chassis
GLASSFANSPSU
Choose your style

CHOOSE YOUR STYLE

C05 whiteC05 black

C05 WHITE

  • Front panel: Plastic + tempered glass
  • Case size: 390 × 215 × 470 mm
  • Warranty: 1 year for case
Key features

PERFORMANCE, WITHOUT THE FUSS

01

PREMIUM DESIGN

Clean gaming-focused chassis with a refined modern look, in SPCC steel (0.5 mm).

02

IMMERSIVE RGB

Rainbow RGB fans on display through the glass.

03

TEMPERED GLASS

Plastic + tempered glass. Packaging notes: handle with care.

04

TRI-SIDE VENTILATION

Dense mesh panels for enhanced airflow and superior heat dissipation.

05

HARDWARE COMPATIBILITY

ATX, Micro-ATX, mini-ITX. GPU up to 340 mm, CPU cooler up to 165 mm, 7 PCI slots.

06

MESH SIDE PANEL

Dense mesh panel with three RGB fans for enhanced airflow.

C05 · MESH SIDE PANEL

MESH, BY
THE NUMBERS.

Dense mesh panel with three RGB fans for enhanced airflow.

C05 MESH SIDE PANEL
Will it fit?

SEE YOUR BUILD INSIDE

Pick your parts and see how they sit against the C05 limits.

ATX BOARDCPU COOLER155 mmlimit 165 mmRADIATOR240 mmlimit 360 mmGRAPHICS CARD300 mmlimit 340 mmPOWER SUPPLY160 mmlimit 160 mm
THIS BUILD FITS
GRAPHICS CARDFITS ✓
40MM CLEARANCE
MAX 340
CPU COOLER HEIGHTFITS ✓
10MM CLEARANCE
MAX 165
RADIATORFITS ✓
120MM CLEARANCE
MAX 360
POWER SUPPLY LENGTHFITS ✓
0MM CLEARANCE
MAX 160
MOTHERBOARDSUPPORTED
Typical sizes shown for illustration. Check your exact parts against the specifications.
Design notes

THE C05, SKETCHED

Infinity RGB fans
M/B side: 12 cm × 3 (included)

Chalk sketch of a C05 RGB fan

Mesh side panel

Chalk sketch of the C05 detail

Front panel: Plastic + tempered glass. The SONIC C05 adds tri-side mesh ventilation and RGB fans, built for EATX, ATX, Micro-ATX, mini-ITX boards, with room for graphics cards up to 340 mm.

Glass front panel,
white or black

Chalk sketch of the C05 glass panel and mesh ventilation

Tri-side ventilation,
dense mesh panels

Cooling

ENGINEERED FOR AIRFLOW

C05 airflowCOOL AIR INCOMPONENTSHOT AIR OUT

Dense mesh panels for enhanced airflow and heat dissipation, with fan and radiator positions across the chassis. Flow lines are illustrative.

COOL AIR IN→COMPONENTS→HOT AIR OUT
  • M/B side: 12 cm × 3 (included)
  • Top: 12 cm × 2 (optional)
  • Rear: 12 cm × 1 (included)
  • Radiator: 120 / 240 / 280 / 360 mm
Inside the chassis

INTERNAL LAYOUT

Six key points inside the C05. Select a point to see what it supports.

C05 · FRONT VIEW390 × 470 mm
C05 interior
Marker positions are indicative.
01 / 06
01

Top cooling

Supports up to a 360 mm radiator or triple 120 mm fans.

Radiator120 / 240 / 280 / 360 mm
FansUp to 3 × 120 mm
Technical

SPECIFICATIONS

ModelC05
Case typeElite Premium compact gaming case, glass front panel
Case size390 × 215 × 470 mm
Chassis size360 × 215 × 470 mm
MaterialSPCC, 0.5 mm
Motherboard supportEATX, ATX, Micro-ATX, mini-ITX
GPU supportVGA length up to 340 mm
CPU cooler supportCPU height up to 165 mm
Fan supportM/B side 12 cm × 3 (included) · Top 12 cm × 2 (optional) · Rear 12 cm × 1 (included)
Radiator support120 / 240 / 280 / 360 mm
StorageHDD × 2, SSD × 2
Front I/OUSB 3.0 × 1, USB 2.0 × 2, HD Audio
PSU supportATX 160 mm
Expansion slots7 PCI
Motherboard standoffsATX, 6 pcs (copper)
Package size530 × 265 × 458 mm
PriceBlack PKR 12,000 · White PKR 12,500

As printed on the SONIC C05 packaging. Packaging lists the chassis (frame) size separately from the overall case size.

C05 White — front view
Downloads

C05 DOCUMENTS

PDFSpecification sheetPrintable. Open it, then print or save as PDF.OPEN →
—Manual & guidesAvailable on request. Ask SONIC on WhatsApp.
