SONICC19
DESIGNED TO DOMINATE. BUILT TO WIN.
SONIC | ELITE PREMIUM GAMING

C19WOODEN EDITION

DESIGNED TO DOMINATE.
BUILT TO WIN.

A premium gaming chassis engineered for powerful hardware, immersive cooling, and a clean modern build.

VIEW SPECIFICATIONS
CONTACT FOR AVAILABILITY
SONIC C19 gaming case
C19  ·  WOODEN EDITION  ·  CRAFTED ACCENT,  ·  C19  ·  WOODEN EDITION  ·  CRAFTED ACCENT,  ·  C19  ·  WOODEN EDITION  ·  CRAFTED ACCENT,  ·  C19  ·  WOODEN EDITION  ·  CRAFTED ACCENT,  ·  C19  ·  WOODEN EDITION  ·  CRAFTED ACCENT,  ·  C19  ·  WOODEN EDITION  ·  CRAFTED ACCENT,  ·
390MM MAX GPU LENGTH
360MM RADIATOR SUPPORT
165MM MAX CPU COOLER
7PCI EXPANSION SLOTS
The C19

A PREMIUM GAMING CHASSIS ENGINEERED FOR POWERFUL HARDWARE, IMMERSIVE COOLING, AND A CLEAN MODERN BUILD.

Technical

PRECISION IN EVERY DIMENSION

Designed to deliver impressive hardware compatibility while maintaining a refined gaming footprint.

Chalk sketch of the C19 front view
460 mm · WIDTH486 mm · HEIGHT
DEPTH215mm · DEPTH
C19

WOOD MEETS
AIRFLOW.

SONIC C19
WOODEN ACCENTFRONT: PLASTIC + MESH NETTRI-SIDE VENTILATION
INSIDE THE C19

EXPLODED VIEW

  1. 01TEMPERED GLASSThe glass panel lifts away to reveal the build.
  2. 02FAN WALLThe side-mounted fans slide out as a unit.
  3. 03POWER BAYThe power supply sits in its own shroud at the base.
  4. 04CHASSISMotherboard, GPU and radiator space stay in the frame.
Scroll to pull the C19 apart. Illustrative layers made from the product photo.
C19 chassis
GLASSFANSPSU
Choose your style

CHOOSE YOUR STYLE

C19 whiteC19 black

C19 WHITE

  • Front panel: Plastic + mesh net
  • Case size: 460 × 215 × 486 mm
  • Warranty: 1 year for case
Key features

CRAFTED ACCENT, PERFORMANCE INSIDE

01

PREMIUM DESIGN

Clean gaming-focused chassis with a refined modern look, in SPCC steel (0.5 mm).

02

IMMERSIVE RGB

Rainbow RGB fans on display through the glass.

03

FRONT PANEL

Plastic + mesh net.

04

TRI-SIDE VENTILATION

Dense mesh panels for enhanced airflow and superior heat dissipation.

05

HARDWARE COMPATIBILITY

ATX, Micro-ATX, mini-ITX. GPU up to 390 mm, CPU cooler up to 165 mm, 7 PCI slots.

06

WOODEN ACCENT

Wooden side trim paired with a ribbed mesh panel.

C19 · WOODEN ACCENT

A WOODEN
ACCENT.

Wooden side trim paired with a ribbed mesh panel.

C19 WOODEN ACCENT
Will it fit?

SEE YOUR BUILD INSIDE

Pick your parts and see how they sit against the C19 limits.

ATX BOARDCPU COOLER155 mmlimit 165 mmRADIATOR240 mmlimit 360 mmGRAPHICS CARD300 mmlimit 390 mmPOWER SUPPLY160 mmlimit 220 mm
THIS BUILD FITS
GRAPHICS CARDFITS ✓
90MM CLEARANCE
MAX 390
CPU COOLER HEIGHTFITS ✓
10MM CLEARANCE
MAX 165
RADIATORFITS ✓
120MM CLEARANCE
MAX 360
POWER SUPPLY LENGTHFITS ✓
60MM CLEARANCE
MAX 220
MOTHERBOARDSUPPORTED
Typical sizes shown for illustration. Check your exact parts against the specifications.
Design notes

THE C19, SKETCHED

Infinity RGB fans
M/B side: 12 cm × 3 (included)

Chalk sketch of a C19 RGB fan

Wooden accent

Chalk sketch of the C19 detail

Front panel: Plastic + mesh net. The SONIC C19 adds tri-side mesh ventilation and RGB fans, built for EATX, ATX, Micro-ATX, mini-ITX boards, with room for graphics cards up to 390 mm.

Front panel: Plastic + mesh net,
white or black

Chalk sketch of the C19 glass panel and mesh ventilation

Tri-side ventilation,
dense mesh panels

Cooling

ENGINEERED FOR AIRFLOW

C19 airflowCOOL AIR INCOMPONENTSHOT AIR OUT

Dense mesh panels for enhanced airflow and heat dissipation, with fan and radiator positions across the chassis. Flow lines are illustrative.

COOL AIR IN→COMPONENTS→HOT AIR OUT
  • M/B side: 12 cm × 3 (included)
  • Top: 12 cm × 3 (optional)
  • Rear: 12 cm × 1 (included)
  • Radiator: 120 / 240 / 280 / 360 mm
Inside the chassis

INTERNAL LAYOUT

Six key points inside the C19. Select a point to see what it supports.

C19 · FRONT VIEW460 × 486 mm
C19 interior
Marker positions are indicative.
01 / 06
01

Top cooling

Supports up to a 360 mm radiator or triple 120 mm fans.

Radiator120 / 240 / 280 / 360 mm
FansUp to 3 × 120 mm
Technical

SPECIFICATIONS

ModelC19
Case typeElite Premium compact gaming case, Plastic + mesh net front panel
Case size460 × 215 × 486 mm
Chassis size420 × 215 × 470 mm
MaterialSPCC, black, 0.5 mm
Motherboard supportEATX, ATX, Micro-ATX, mini-ITX
GPU supportVGA length up to 390 mm
CPU cooler supportCPU height up to 165 mm
Fan supportM/B side 12 cm × 3 (included) · Top 12 cm × 3 (optional) · Rear 12 cm × 1 (included)
Radiator support120 / 240 / 280 / 360 mm
StorageHDD × 2, SSD × 2
Front I/OUSB 3.0 × 1, USB 2.0 × 2, HD Audio
PSU supportATX 220 mm
Expansion slots7 PCI
Motherboard standoffsATX, 6 pcs (copper)
Package size530 × 268 × 523 mm
PriceBlack PKR 14,000 · White PKR 14,500

As printed on the SONIC C19 packaging. Packaging lists the chassis (frame) size separately from the overall case size.

C19 White — front view
Downloads

C19 DOCUMENTS

PDFSpecification sheetPrintable. Open it, then print or save as PDF.OPEN →
—Manual & guidesAvailable on request. Ask SONIC on WhatsApp.
